UPVC Water Supply Pipe

UPVC water supply pipe, officially known as rigid polyvinyl chloride water supply pipe, is a pipe material used for pressure water transmission. It is made from polyvinyl chloride resin as the main raw material, without adding plasticizers, and with necessary stabilizers, lubricants, etc., through extrusion molding. It was once the main product in the global "plastic replacing steel" strategy, replacing traditional galvanized steel pipes and cast iron pipes.

Brand Quality Service

The best UPVC pipe manufacturers and water supply solution providers in China

UPVC PIPE

Outstanding in terms of economy

The price per unit length of the same specification is only half that of galvanized pipes. The installation cost is 70% lower than that of galvanized pipes, and the total project investment can be reduced by 15% to 25%.

UPVC PIPE

Portable and easy to install

The weight is only 20% to 30% of that of cast iron pipes, the transportation cost is reduced by 20% to 60%, the installation time is saved by 40% to 75%, and it can greatly reduce the labor intensity of workers.

UPVC PIPE

Water quality and hygiene safety

The residual amount of vinyl chloride monomer in the production formula is extremely low. The amount that diffuses into water is far below the national drinking water standards and will not cause pollution to the water quality.

UPVC PIPE

Resistant to corrosion and free from scaling

It has excellent acid and alkali resistance and can be directly laid in corrosive soil without the need for anti-corrosion treatment. The inner wall is smooth (with a roughness coefficient of only 0.009), and it is not prone to scaling. The water transmission capacity can be 30% to 50% higher than that of cast iron pipes.

Our production and equipment

years

Our UPVC pipe production line has been fully put into use since 2015.

team

Our factory has 50 technical R & D personnel and production staff.

awards

We have a comprehensive certification system of certificates in the field of UPVC pipes.

Nominal Outer Diameter	Commonly ranges from DN15 to DN300
Density	1.35 - 1.46 g/cm³
Tensile Strength	Not less than 40 MPa
Hygienic Performance	GB/T 10002.1
Chemical Corrosion Resistance	It has good corrosion resistance to most inorganic acids, alkalis, salts, etc. Avoid contact with strong oxidizing acids such as concentrated nitric acid and fuming sulfuric acid, as well as certain organic solvents.

The main weaknesses and limitations

Sensitive to temperature: Suitable for applications where the water temperature does not exceed 45℃. It cannot be used for hot water transportation. The material will become brittle at low temperatures. During winter construction and operation, measures should be taken to prevent freezing.

Poor impact resistance: The material is relatively hard and brittle. During construction and transportation, it is necessary to prevent impacts such as bumps, collisions, drops, and compressions to avoid physical damage.
Thermal expansion and contraction are obvious: The coefficient of linear expansion is relatively large. In pipeline design, temperature compensation measures need to be considered, such as installing expansion joints.
Not suitable as an electrical conduit: As it is an insulator, it cannot serve as the grounding circuit for the wires, thus it cannot be used as an electrical conduit.

How To Cooperate With Us?

Our company adopts a dual-channel procurement model of both online and offline. If you need it, you can choose to visit our offline factory or communicate directly with the salesperson online.
